Automatic Carton Folding Sealing Machine TOCS-5A

description1
Zipper closure 1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout
Introduction

Automatic carton sealer is suitable for circumstance where the size of cartons does not change frequently,which especially fits for continuous sealing of cartons in the same size.The machine is used in the fields of domestic electrical appliance,foodstuffs,general merchandise,medicine and chemical industries.And this machine with flaps folding function.

Features
  • Imported accessories, electrical and pneumatic components
  • Realize fold the box flaps automatically
  • Manually adjustable the height and the width for different size of cartons
  • Top&bottom belts driven, carton sealing in top
  • Cutter Safety system to prevent hands form stabbed by the cutter
  • Both steel and stainless steel types
  • Also suitable for cartons with side covers
  • Top and bottom movement can be interchanged
  • Height of working table can be adjustabl
Technical Parameters

Model

TOCS-5A

Power supply

AC220V/50,AC110V/60Hz 420W

Max. packing dimension

500(W)* 500(H)* 600(L)mm

Min. packing dimension

200(W)*150 (H)*200 (L)mm

Air Pressure

2/3L, 5Kg/cm²

Working table height:

600-700mm

speed

18m/min

Width of adhesive tape

48mm. 60mm. 75mm

Machine size

2836×1010×(1600-1700)MM
