Double Heads Weighing Filling Machine TOWF20L-2

description1
Zipper closure 1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout
Introduction

This machine can be used for all kinds of intelligent and quantitative filling without air fluids and semi -current, and widely available scope, such as edible oil, lubricant, antifreeze, urea, paint, waterproof coatings, liquid fertilizer, daily sugar paddle, etc. The sticky liquid is an ideal model of various food industries and daily chemical industries. This machine adopts an automatic way to make the measurement more accurate and more convenient to operate.

Major Characteristics

1.This machine is controlled by a programmable controller (PLC). With the digital transmission module, the touch screen input operation has the characteristics of convenient operation and high production efficiency.



2.The appearance of this machine is humane design, beautiful and generous, and the body is made of stainless steel. Electric components are well -known brands with reliable performance and stable and durable.



3.The degree of automation of this machine is high. The measurement adjustment is implemented in the touch screen. Intelligencemakes the operation of the machine more reliable and convenient, and the human -machine interface is more friendly.



4.All contacts with the material with the material are made of high -quality 304 stainless steel. It is an ideal packaging equipment for the chemical industry.



5.This machine uses dive irrigation and anti -drip leakage valve, which can effectively prevent pollution caused by dripping liquid due to droplets.



6.The built -in power pump of this machine is not required to be equipped with high tanks, simplifying the installation process, and saving customer costs.

Technical Parameters

Model

TOWF20L-2

Follow the number

2

Infusion capacity

10-20kg

Production

60-100 barrels/hour (change from different viscosity)

Power Supply

380V 50Hz three -phase 2.2kw

Require gas source

0.6MPa

Precision

≤ 0.2﹪

Dimension

850mm *900mm*1600mm

Weight

220kgs
