Round Bottle Labeling Machine TORL-630B

description1
Zipper closure 1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout
Description

1.This machine is used for using the Taiwan touching type of PLC control or knob control. It is made up of photo-electricity equipment of Japan OMRON. Synchronization electrical, timing electrical, conveyer belt. Import strap etc correlative part.

2.The design of mainframe part absorbed label transmit of import machine and solved the unsteady ingredient of homemade common label.

3.The machine is suitable for various specifications of bottles. Its operation is easy and it can be finished in a short time.

4.The quick printer adopts the motor drive, gas drive. The words in the ribbon are clear and clean.

5.The whole machine is designed to meet GMP standard.

6.This machine is suitable for processing the big round label of medicine, chemical, food, commodity etc.

Main Technical Parameters

Model

TORL-630B

Inner diameter of label

76mm

Max outer diameter of label

300mm

Label length

10- 350mm

Label width

10- 200mm

Bottle diameter

10-150mm

Tolerance of labeling

±1mm

Power supply

220-50/60HZ (according to the customer's requirement)

Power

400W

Dimension(L*W*H)

2000mm*950mm*1260mm

Weight

170Kg

Production capacity

30-100 bottles/min
